Alignment Scissor Lift IT8534

New

$6,400.00

Buy in one click

More info

Description

● 4000kg lifting capacity;

● Standard Wheel Free Lift;

● Above-ground installation;

● Low profile runways needs less space and allows the vehicles drive on and off conveniently;

● Electrical leveling;

● Infrared synchronization protection system;

● Long slip plate and adjustable turntable positions accommodate different kinds of wheelbases;

● Pneumatic safety locking system;

● 24V safe control system;

● The alarm buzzer for safe descending;

● Anti-surge valve prevents sudden lowering in case hydraulic hose broken.

Data sheet

Data sheet

Model name IT8534
Lifting capacity 4000KG
Net weight 2350KG
Max lifting height 1800mm
Overall width 2130mm
Runway length 4500mm
Runway width 600mm
Capacity of motor 2.2kw
Power supply 110/220/380V, 50/60Hz
