Description
● 5000kg lifting capacity;
● Its base plate design demands less storey height;
● Chain lifting system combined with dual hydraulic cylinders;
● Electrical release, just press Up and Down button to operate the lift;
● The 24V ABS control box and limit switch consider your safety operation;
● Feet protection bar and door opening protection rubber pad effectively avoid unexpected injuries and damages;
● With height adapters for servicing light-duty trucks;
● Reserved hand pump joint on hydraulic block for emergency lowering;
● It has been proofed by dynamic test with 115% of rated capacity and static test with 150% of rated capacity;
● CE certificated.
Data sheet
Data sheet
Model name | IT8215E |
Lifting capacity | 5000KG |
Net weight | 920KG |
Max lifting height | 1900mm |
Min pad height | 100mm |
Overall height | 2912mm |
Overall width | 4028mm |
Capacity of motor | 2.2KW |
Power supply | 110/220/380V, 50/60Hz |
