New product

Tire Changer IT613

New

$890.00

Buy in one click

More info

Description

● For standard, low-profile and run-flat wheels of car and light commercial vehicles;

● Machine post tilted backwards / forwards upon pedal operation (pneumatic) and pneumatically locked in working position;

● Locking rim from 10”-24”;

● Pedal assembly may draw from front cover;

● Self-centering four-jaw turntable controlled via two clamping cylinders for correct clamping of the wheel;

● Plastic protection inside jaws and on mounting head to avoid damage to alloy rims;

● Large bead breaker blade;

● Bead breaker with large anti-skid rubber pad.

Data sheet

Data sheet

Model name IT613
Motor power 1.1/0.75kw
Max wheel diameter 41”(1040mm)
Max wheel width 14”(355mm)
Outside clamping 10”~21”
Inside clamping 12”~24”
Air supply 8-10bar
Bead breaker force 2500kg
Power supply 110/220/380V, 50/60Hz
Net weight / Gross weight 218/248kg
Packing dimension 1080*900*960mm
